CD74HC688E
RoHS
/
Package 20-DIP (0.300, 7.62mm)
Category Integrated Circuits (ICs) / Logic - Comparators
Description
CMOS Active Low Not Qualified Identity Comparator Identity Comparator -55C~125C 5V 29ns @ 6V 50pF 255ns
PDF
/
Buying Options
Total Price: USD $1.9
Unit Price: USD $1.9008
≥1 USD $1.9008
≥10 USD $1.70544
≥100 USD $1.60864
≥500 USD $1.3706
≥1000 USD $1.286965
≥3000 USD $1.126118
Inventory: 312
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status Non-RoHS Compliant
Technical
Output Function A=B
Propagation Delay (tpd) 255 ns
Max Propagation Delay @ V, Max CL 29ns @ 6V, 50pF
Current - Output High, Low 5.2mA 5.2mA
Current - Quiescent (Iq) 8μA
Family HC/UH
Number of Bits 8
Supply Voltage-Min (Vsup) 2V
Supply Voltage-Max (Vsup) 6V
Qualification Status Not Qualified
JESD-30 Code R-PDIP-T20
Output Active Low
Supply Voltage 5V
Number of Functions 1
Terminal Position DUAL
Voltage - Supply 2V~6V
Technology CMOS
Additional Feature CASCADABLE
Type Identity Comparator
Number of Terminations 20
Moisture Sensitivity Level (MSL) 3 (168 Hours)
Part Status Obsolete
Series 74HC
Packaging Tube
Operating Temperature -55°C~125°C
Physical
Surface Mount NO
Package / Case 20-DIP (0.300, 7.62mm)
Mounting Type Through Hole
