74AC520PC
RoHS
RoHS compliant
RoHS compliantPackage 20-DIP (0.300, 7.62mm)
Category Integrated Circuits (ICs) / Logic - Comparators
Description
WITH PULLUP RESISTORS ON B INPUTS; CASCADABLE Tube AC 74AC digital comparator 24mA 24mA 13.5ns 7.62mm 9ns @ 5V 50pF
PDF
/
Buying Options
Total Price: USD $0.29
Unit Price: USD $0.2904
≥1 USD $0.2904
Inventory: 1605
Minimum: 1
-
+
Technical Details
Physical
Mounting Type Through Hole
Package / Case 20-DIP (0.300, 7.62mm)
Surface Mount NO
Number of Pins 20
Technical
Operating Temperature -40°C~85°C
Packaging Tube
Series 74AC
Pbfree Code yes
Part Status Obsolete
Moisture Sensitivity Level (MSL) 3 (168 Hours)
Number of Terminations 20
Type Identity Comparator
Additional Feature WITH PULLUP RESISTORS ON B INPUTS; CASCADABLE
Technology CMOS
Voltage - Supply 2V~6V
Terminal Position DUAL
Peak Reflow Temperature (Cel) NOT SPECIFIED
Number of Functions 1
Terminal Pitch 2.54mm
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Output Active Low
Pin Count 20
Qualification Status Not Qualified
Supply Voltage-Max (Vsup) 6V
Supply Voltage-Min (Vsup) 2V
Number of Bits 8
Family AC
Current - Quiescent (Iq) 4μA
Current - Output High, Low 24mA 24mA
Max Propagation Delay @ V, Max CL 9ns @ 5V, 50pF
Propagation Delay (tpd) 13.5 ns
Output Function A=B
Dimensions
Length 26.075mm
Width 7.62mm
Compliance
RoHS Status ROHS3 Compliant
Lead Free Lead Free
