MM74C85N
RoHS
/
Package 16-DIP (0.300, 7.62mm)
Category Integrated Circuits (ICs) / Logic - Comparators
Description
Lead Free Inverting Active Low Magnitude Comparator Magnitude Comparator -55C~125C 15V 300ns @ 10V 50pF 600ns
PDF
/
Buying Options
Total Price: USD $15.21
Unit Price: USD $15.2064
≥1 USD $15.2064
Inventory: 4930
Minimum: 1
-
+
Technical Details
Physical
Mount Through Hole
Mounting Type Through Hole
Package / Case 16-DIP (0.300, 7.62mm)
Number of Pins 16
Supplier Device Package 16-PDIP
Technical
Operating Temperature -55°C~125°C
Packaging Tube
Published 2002
Series 74C
Part Status Obsolete
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Type Magnitude Comparator
Max Operating Temperature 125°C
Min Operating Temperature -55°C
Voltage - Supply 3V~15V
Base Part Number 74C85
Output Active Low
Polarity Inverting
Max Supply Voltage 15V
Min Supply Voltage 3V
Number of Bits 4
Propagation Delay 300 ns
Turn On Delay Time 600 ns
Current - Output High, Low 15mA 16mA
Max Propagation Delay @ V, Max CL 300ns @ 10V, 50pF
High Level Output Current 16mA
Low Level Output Current 15mA
Output Function AB
Compliance
RoHS Status RoHS Compliant
Lead Free Lead Free
