N74F85D,518
RoHS
RoHS compliant
RoHS compliantPackage 16-SOIC (0.154, 3.90mm Width)
Category Integrated Circuits (ICs) / Logic - Comparators
Description
1999 Tape & Reel (TR) F/FAST e4 digital comparator 1mA 20mA 15.5ns 7.5mm 50pF
PDF
/
Inventory: 1162
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Dimensions
Width 7.5mm
Length 10.3mm
Height Seated (Max) 2.65mm
Technical
Output Function AB
Propagation Delay (tpd) 15.5 ns
Max Propagation Delay @ V, Max CL 14ns @ 5V, 50pF
Current - Output High, Low 1mA 20mA
Family F/FAST
Number of Bits 4
Load Capacitance 50pF
Supply Voltage-Max (Vsup) 5.5V
Qualification Status Not Qualified
JESD-30 Code R-PDSO-G16
Pin Count 16
Output Active High
Base Part Number 74F85
Time@Peak Reflow Temperature-Max (s) 30
Terminal Pitch 1.27mm
Supply Voltage 5V
Number of Functions 1
Peak Reflow Temperature (Cel) 260
Terminal Form GULL WING
Terminal Position DUAL
Voltage - Supply 4.5V~5.5V
Technology TTL
Terminal Finish NICKEL PALLADIUM GOLD
Type Magnitude Comparator
Number of Terminations 16
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Obsolete
JESD-609 Code e4
Series 74F
Published 1999
Packaging Tape & Reel (TR)
Operating Temperature 0°C~70°C
Physical
Surface Mount YES
Package / Case 16-SOIC (0.154, 3.90mm Width)
Mounting Type Surface Mount
