SN74S244N
RoHS
RoHS compliant
RoHS compliantPackage 20-DIP (0.300, 7.62mm)
Category Integrated Circuits (ICs) / Logic - Buffers, Drivers, Receivers, Transceivers
Description
74S244 Tube Nickel/Palladium/Gold (Ni/Pd/Au) 74S logic receiver 15mA 64mA 15ns 5.08mm 5V
PDF
/
Buying Options
Total Price: USD $0.83
Unit Price: USD $0.8303
≥1 USD $0.8303
≥10 USD $0.68115
≥100 USD $0.66025
≥500 USD $0.6384
≥1000 USD $0.6175
Inventory: 1435
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 6 Weeks
Lifecycle Status ACTIVE (Last Updated: 3 days ago)
Physical
Mount Through Hole
Mounting Type Through Hole
Package / Case 20-DIP (0.300, 7.62mm)
Number of Pins 20
Technical
Operating Temperature 0°C~70°C TA
Packaging Tube
Series 74S
JESD-609 Code e4
Pbfree Code yes
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 20
Termination Through Hole
ECCN Code EAR99
Terminal Finish Nickel/Palladium/Gold (Ni/Pd/Au)
Subcategory Bus Driver/Transceivers
Technology TTL
Voltage - Supply 4.75V~5.25V
Terminal Position DUAL
Number of Functions 2
Supply Voltage 5V
Base Part Number 74S244
Pin Count 20
Output Type 3-State
Operating Supply Voltage 5V
Number of Elements 2
Polarity Non-Inverting
Power Supplies 5V
Number of Circuits 8
Operating Supply Current 100μA
Load Capacitance 50pF
Number of Ports 2
Nominal Supply Current 100μA
Propagation Delay 9 ns
Quiescent Current 120mA
Turn On Delay Time 15 ns
Family S
Logic Function Buffer, Inverting
Current - Output High, Low 15mA 64mA
Logic Type Buffer, Non-Inverting
Number of Bits per Element 4
Control Type ENABLE LOW
Number of Output Lines 3
Count Direction UNIDIRECTIONAL
Dimensions
Height 5.08mm
Length 24.33mm
Width 6.35mm
Thickness 4.57mm
Compliance
Radiation Hardening No
REACH SVHC No SVHC
RoHS Status ROHS3 Compliant
Lead Free Lead Free
