SN74S244DW

Texas Instruments
RoHS
RoHS RoHS compliant
Package 20-SOIC (0.295, 7.50mm Width)
Category Integrated Circuits (ICs) / Logic - Buffers, Drivers, Receivers, Transceivers
Description 74S244 Tube Not Qualified Nickel/Palladium/Gold (Ni/Pd/Au) logic receiver 15mA 64mA 15ns 2.65mm 5V
PDF
/
Buying Options
Total Price: USD $10.59
Unit Price: USD $10.589851
≥1 USD $10.589851
≥200 USD $4.098874
≥500 USD $3.954455
≥1000 USD $3.883558
Inventory: 8523
Minimum: 1
-
+

Technical Details

Compliance

Lead Free Lead Free
RoHS Status ROHS3 Compliant
REACH SVHC No SVHC

Dimensions

Thickness 2.35mm
Width 7.5mm
Length 12.8mm
Height 2.65mm

Technical

Count Direction UNIDIRECTIONAL
Number of Output Lines 3
Number of Input Lines 8
Control Type ENABLE LOW
Number of Bits per Element 4
Logic Type Buffer, Non-Inverting
Current - Output High, Low 15mA 64mA
Logic Function Buffer, Inverting
Family S
Turn On Delay Time 15 ns
Quiescent Current 120mA
Propagation Delay 9 ns
Number of Ports 2
Load Capacitance 50pF
Power Supplies 5V
Polarity Non-Inverting
Number of Elements 2
Operating Supply Voltage 5V
Output Type 3-State
Qualification Status Not Qualified
Pin Count 20
Base Part Number 74S244
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Supply Voltage 5V
Number of Functions 2
Peak Reflow Temperature (Cel) 260
Terminal Form GULL WING
Terminal Position DUAL
Voltage - Supply 4.75V~5.25V
Technology TTL
Subcategory Bus Driver/Transceivers
Terminal Finish Nickel/Palladium/Gold (Ni/Pd/Au)
ECCN Code EAR99
Termination SMD/SMT
Number of Terminations 20
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Pbfree Code yes
JESD-609 Code e4
Series 74S
Packaging Tube
Operating Temperature 0°C~70°C TA

Physical

Number of Pins 20
Package / Case 20-SOIC (0.295, 7.50mm Width)
Mounting Type Surface Mount
Mount Surface Mount

Supply Chain

Lifecycle Status ACTIVE (Last Updated: 5 days ago)
Factory Lead Time 6 Weeks

Alternative Model
