SN74S240DWR
RoHS
RoHS compliant
RoHS compliantPackage 20-SOIC (0.295, 7.50mm Width)
Category Integrated Circuits (ICs) / Logic - Buffers, Drivers, Receivers, Transceivers
Description
ROHS3Compliant Lead Free DUAL TTL Logic Buffer, Inverting 0C~70C TA 50pF 5V 7.5mm
PDF
/
Buying Options
Total Price: USD $1.82
Unit Price: USD $1.8164
≥1 USD $1.8164
≥10 USD $1.49055
≥100 USD $1.444
≥500 USD $1.39745
≥1000 USD $1.3509
Inventory: 1254
Minimum: 1
-
+
Technical Details
Physical
Mount Surface Mount
Mounting Type Surface Mount
Package / Case 20-SOIC (0.295, 7.50mm Width)
Number of Pins 20
Technical
Operating Temperature 0°C~70°C TA
Packaging Tape & Reel (TR)
Series 74S
JESD-609 Code e4
Part Status Obsolete
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 20
Terminal Finish Nickel/Palladium/Gold (Ni/Pd/Au)
Subcategory Bus Driver/Transceivers
Packing Method TAPE AND REEL
Technology TTL
Voltage - Supply 4.75V~5.25V
Terminal Position DUAL
Terminal Form GULL WING
Peak Reflow Temperature (Cel) 260
Number of Functions 2
Supply Voltage 5V
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Base Part Number 74S240
Pin Count 20
Qualification Status Not Qualified
Output Type 3-State
Operating Supply Voltage 5V
Number of Elements 2
Polarity Inverting
Power Supplies 5V
Number of Channels 8
Load Capacitance 50pF
Number of Ports 2
Number of Bits 6
Propagation Delay 7 ns
Quiescent Current 100mA
Turn On Delay Time 15 ns
Family S
Logic Function Buffer, Inverter
Current - Output High, Low 15mA 64mA
Logic Type Buffer, Inverting
Number of Bits per Element 4
Control Type ENABLE LOW
Power Supply Current-Max (ICC) 150mA
Number of Output Lines 3
Dimensions
Width 7.5mm
Compliance
RoHS Status ROHS3 Compliant
Lead Free Lead Free
