SN74LVC3G34DCTR
RoHS
RoHS compliant
RoHS compliantPackage 8-LSSOP, 8-MSOP (0.110, 2.80mm Width)
Category Integrated Circuits (ICs) / Logic - Buffers, Drivers, Receivers, Transceivers
Description
74LVC3G34 Cut Tape (CT) 74LVC LVC/LCX/Z logic buffer 32mA 32mA 7.9ns 1.3mm 3.3V
PDF
/
Buying Options
Total Price: USD $0.21
Unit Price: USD $0.2147
≥1 USD $0.2147
≥10 USD $0.1767
≥100 USD $0.171
≥500 USD $0.1653
≥1000 USD $0.16055
Inventory: 38355
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Lead Free
RoHS Status ROHS3 Compliant
REACH SVHC No SVHC
Dimensions
Thickness 1.29mm
Width 2.8mm
Length 2.95mm
Height 1.3mm
Technical
Schmitt Trigger Input No
Number of Bits per Element 1
Logic Type Buffer, Non-Inverting
Current - Output High, Low 32mA 32mA
Number of Inputs 3
Logic Function Buffer, Inverting
Family LVC/LCX/Z
Turn On Delay Time 7.9 ns
Quiescent Current 10μA
Propagation Delay 3.2 ns
Output Current 32mA
Nominal Supply Current 250mA
Load Capacitance 50pF
Number of Channels 3
Supply Voltage-Max (Vsup) 5.5V
Polarity Non-Inverting
Output Type Push-Pull
Pin Count 8
Base Part Number 74LVC3G34
Terminal Pitch 0.65mm
Supply Voltage 3.3V
Number of Functions 3
Peak Reflow Temperature (Cel) 260
Terminal Form GULL WING
Terminal Position DUAL
Voltage - Supply 1.65V~5.5V
Technology CMOS
Packing Method TR
Subcategory Gates
ECCN Code EAR99
Number of Terminations 8
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Pbfree Code yes
JESD-609 Code e4
Series 74LVC
Packaging Cut Tape (CT)
Operating Temperature -40°C~125°C TA
Physical
Number of Pins 8
Package / Case 8-LSSOP, 8-MSOP (0.110, 2.80mm Width)
Mounting Type Surface Mount
Mount Surface Mount
Contact Plating Gold
Supply Chain
Lifecycle Status ACTIVE (Last Updated: 3 days ago)
Factory Lead Time 6 Weeks
