SN74LVC244APW
RoHS
RoHS compliant
RoHS compliantPackage 20-TSSOP (0.173, 4.40mm Width)
Category Integrated Circuits (ICs) / Logic - Buffers, Drivers, Receivers, Transceivers
Description
74LVC244 Tube Not Qualified 74LVC logic buffer 24mA 24mA 19.8ns 1.2mm 500mW
PDF
/
Buying Options
Total Price: USD $1.11
Unit Price: USD $1.1088
≥1 USD $1.1088
≥10 USD $0.99088
≥100 USD $0.94072
≥500 USD $0.772702
≥1000 USD $0.722322
≥3000 USD $0.638334
Inventory: 1090
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 6 Weeks
Lifecycle Status ACTIVE (Last Updated: 4 days ago)
Physical
Contact Plating Gold
Mount Surface Mount
Mounting Type Surface Mount
Package / Case 20-TSSOP (0.173, 4.40mm Width)
Number of Pins 20
Technical
Operating Temperature -40°C~125°C TA
Packaging Tube
Series 74LVC
JESD-609 Code e4
Pbfree Code yes
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 20
Termination SMD/SMT
ECCN Code EAR99
Subcategory Bus Driver/Transceivers
Max Power Dissipation 500mW
Technology CMOS
Voltage - Supply 1.65V~3.6V
Terminal Position DUAL
Terminal Form GULL WING
Peak Reflow Temperature (Cel) 260
Number of Functions 2
Supply Voltage 1.8V
Terminal Pitch 0.65mm
Frequency 100MHz
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Base Part Number 74LVC244
Pin Count 20
Qualification Status Not Qualified
Output Type 3-State
Operating Supply Voltage 1.8V
Number of Elements 2
Polarity Non-Inverting
Number of Circuits 8
Number of Ports 2
Nominal Supply Current 1μA
Propagation Delay 3.9 ns
Quiescent Current 1μA
Turn On Delay Time 19.8 ns
Family LVC/LCX/Z
Logic Function Buffer, Inverting
Number of Inputs 1
Current - Output High, Low 24mA 24mA
Logic Type Buffer, Non-Inverting
Number of Bits per Element 4
Control Type ENABLE LOW
Number of Output Lines 3
Count Direction UNIDIRECTIONAL
Max Junction Temperature (Tj) 150°C
Ambient Temperature Range High 125°C
Dimensions
Height 1.2mm
Length 6.5mm
Width 4.4mm
Thickness 1mm
Compliance
REACH SVHC No SVHC
RoHS Status ROHS3 Compliant
Lead Free Lead Free
