SN74LVC1G17YEAR
RoHS
RoHS compliant
RoHS compliantPackage 5-XFBGA, DSBGA
Category Integrated Circuits (ICs) / Logic - Buffers, Drivers, Receivers, Transceivers
Description
ROHS3Compliant Contains Lead Schmitt Trigger BOTTOM Logic Buffer, Non-Inverting -40C~85C TA 50pF 1.8V 0.5mm
PDF
/
Buying Options
Total Price: USD $0.28
Unit Price: USD $0.275417
≥1 USD $0.275417
≥10 USD $0.259818
≥100 USD $0.245117
≥500 USD $0.23124
≥1000 USD $0.218154
Inventory: 961
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Contains Lead
RoHS Status ROHS3 Compliant
Dimensions
Width 0.9mm
Height Seated (Max) 0.5mm
Technical
Schmitt Trigger YES
Prop. Delay@Nom-Sup 5.5 ns
Max I(ol) 0.024 A
Logic Type Buffer, Non-Inverting
Current - Output High, Low 32mA 32mA
Number of Inputs 1
Logic Function Buffer, Schmitt Trigger
Family LVC/LCX/Z
Input Type Schmitt Trigger
Load Capacitance 50pF
Power Supplies 3.3V
Supply Voltage-Max (Vsup) 5.5V
Number of Elements 1
Output Type Push-Pull
Qualification Status Not Qualified
JESD-30 Code R-XBGA-B5
Pin Count 5
Base Part Number 74LVC1G17
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Reach Compliance Code not_compliant
Terminal Pitch 0.5mm
Supply Voltage 1.8V
Number of Functions 1
Peak Reflow Temperature (Cel) NOT SPECIFIED
Terminal Form BALL
Terminal Position BOTTOM
Voltage - Supply 1.65V~5.5V
Technology CMOS
Packing Method TAPE AND REEL
Subcategory Gates
Number of Terminations 5
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Obsolete
Series 74LVC
Packaging Cut Tape (CT)
Operating Temperature -40°C~85°C TA
Physical
Package / Case 5-XFBGA, DSBGA
Mounting Type Surface Mount
Mount Surface Mount
