SN74LS623N
RoHS
RoHS compliant
RoHS compliantPackage 20-DIP (0.300, 7.62mm)
Category Integrated Circuits (ICs) / Logic - Buffers, Drivers, Receivers, Transceivers
Description
74LS623 Tube WITH INDEPENDENT OUTPUT ENABLE FOR EACH DIRECTION Nickel/Palladium/Gold (Ni/Pd/Au) logic buffer 15mA 24mA 40ns 5.08mm 5V
PDF
/
Buying Options
Total Price: USD $3.87
Unit Price: USD $3.872
≥1 USD $3.872
Inventory: 1178
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Contains Lead
RoHS Status ROHS3 Compliant
REACH SVHC No SVHC
Radiation Hardening No
Dimensions
Thickness 4.57mm
Width 6.35mm
Length 24.33mm
Height 5.08mm
Technical
Translation N/A
Power Supply Current-Max (ICC) 0.09mA
Schmitt Trigger No
Control Type INDEPENDENT CONTROL
Max I(ol) 0.024 A
Logic Type Transceiver, Non-Inverting
Current - Output High, Low 15mA 24mA
Direction Bidirectional
Logic Function Inverting, Transceiver
Family LS
Turn On Delay Time 40 ns
Propagation Delay 15 ns
Number of Bits 8
Number of Ports 2
Load Capacitance 45pF
Number of Channels 8
Power Supplies 5V
Polarity Non-Inverting
Number of Elements 1
Operating Supply Voltage 5V
Output Type 3-State
Pin Count 20
Base Part Number 74LS623
Terminal Pitch 2.54mm
Supply Voltage 5V
Number of Functions 1
Terminal Position DUAL
Voltage - Supply 4.75V~5.25V
Technology TTL
Subcategory Bus Driver/Transceivers
Additional Feature WITH INDEPENDENT OUTPUT ENABLE FOR EACH DIRECTION
Terminal Finish Nickel/Palladium/Gold (Ni/Pd/Au)
Termination Through Hole
Number of Terminations 20
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Pbfree Code yes
JESD-609 Code e4
Series 74LS
Packaging Tube
Operating Temperature 0°C~70°C TA
Physical
Weight 1.1991g
Number of Pins 20
Package / Case 20-DIP (0.300, 7.62mm)
Mounting Type Through Hole
Mount Through Hole
Supply Chain
Lifecycle Status ACTIVE (Last Updated: 5 days ago)
Factory Lead Time 6 Weeks
