SN74LS07DRE4
RoHS
RoHS compliant
RoHS compliantPackage 14-SOIC (0.154, 3.90mm Width)
Category Integrated Circuits (ICs) / Logic - Buffers, Drivers, Receivers, Transceivers
Description
74LS07 Tape & Reel (TR) Nickel/Palladium/Gold (Ni/Pd/Au) 74LS logic receiver - 40mA 30ns 1.75mm 140mW
PDF
/
Buying Options
Total Price: USD $0.62
Unit Price: USD $0.616
≥1 USD $0.616
≥10 USD $0.53944
≥100 USD $0.50688
≥500 USD $0.413776
≥1000 USD $0.384314
≥3000 USD $0.327078
Inventory: 1816
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Lead Free
RoHS Status ROHS3 Compliant
Radiation Hardening No
Dimensions
Thickness 1.58mm
Width 3.91mm
Length 8.65mm
Height 1.75mm
Technical
Number of Output Lines 6
Power Supply Current-Max (ICC) 45mA
Schmitt Trigger NO
Number of Bits per Element 1
Max I(ol) 0.04 A
Logic Type Buffer, Non-Inverting
Current - Output High, Low - 40mA
Logic Function Buffer, Inverting
Family LS
Turn On Delay Time 30 ns
Propagation Delay 30 ns
Number of Channels 6
Polarity Non-Inverting
Operating Supply Voltage 5V
Output Type Open Collector
Pin Count 14
Base Part Number 74LS07
Supply Voltage 5V
Number of Functions 6
Peak Reflow Temperature (Cel) 260
Terminal Form GULL WING
Terminal Position DUAL
Voltage - Supply 4.75V~5.25V
Technology TTL
Max Power Dissipation 140mW
Packing Method TR
Subcategory Gates
Terminal Finish Nickel/Palladium/Gold (Ni/Pd/Au)
ECCN Code EAR99
Number of Terminations 14
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Pbfree Code yes
JESD-609 Code e4
Series 74LS
Packaging Tape & Reel (TR)
Operating Temperature 0°C~70°C TA
Physical
Number of Pins 14
Package / Case 14-SOIC (0.154, 3.90mm Width)
Mounting Type Surface Mount
Mount Surface Mount
Supply Chain
Lifecycle Status ACTIVE (Last Updated: 3 days ago)
Factory Lead Time 6 Weeks
