SN74HCT244DBR

Texas Instruments
RoHS
RoHS RoHS compliant
Package 20-SSOP (0.209, 5.30mm Width)
Category Integrated Circuits (ICs) / Logic - Buffers, Drivers, Receivers, Transceivers
Description 74HCT244 Cut Tape (CT) 74HCT HCT logic receiver 6mA 6mA 45ns 2mm 5V
PDF
/
Buying Options
Total Price: USD $0.14
Unit Price: USD $0.13887
≥1 USD $0.13887
≥10 USD $0.13101
≥100 USD $0.1236
≥500 USD $0.1166
≥1000 USD $0.11
≥3000 USD $0.10377
Inventory: 7541
Minimum: 1
-
+

Technical Details

Compliance

Lead Free Lead Free
RoHS Status ROHS3 Compliant
Radiation Hardening No

Dimensions

Thickness 1.95mm
Width 5.3mm
Length 7.2mm
Height 2mm

Technical

Count Direction UNIDIRECTIONAL
Number of Input Lines 8
Power Supply Current-Max (ICC) 0.16mA
Control Type ENABLE LOW
Prop. Delay@Nom-Sup 35 ns
Number of Bits per Element 4
Max I(ol) 0.006 A
Logic Type Buffer, Non-Inverting
Current - Output High, Low 6mA 6mA
Logic Function Buffer, Inverting
Family HCT
Turn On Delay Time 45 ns
Quiescent Current 8μA
Propagation Delay 40 ns
Number of Ports 2
Load Capacitance 50pF
Power Supplies 5V
Polarity Non-Inverting
Number of Elements 2
Operating Supply Voltage 5V
Output Type 3-State
Pin Count 20
Base Part Number 74HCT244
Terminal Pitch 0.65mm
Supply Voltage 5V
Number of Functions 2
Peak Reflow Temperature (Cel) 260
Terminal Form GULL WING
Terminal Position DUAL
Voltage - Supply 4.5V~5.5V
Technology CMOS
Packing Method TR
Subcategory Bus Driver/Transceivers
ECCN Code EAR99
Number of Terminations 20
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Pbfree Code yes
JESD-609 Code e4
Series 74HCT
Packaging Cut Tape (CT)
Operating Temperature -40°C~85°C TA

Physical

Number of Pins 20
Package / Case 20-SSOP (0.209, 5.30mm Width)
Mounting Type Surface Mount
Mount Surface Mount
Contact Plating Gold

Supply Chain

Lifecycle Status ACTIVE (Last Updated: 5 days ago)
Factory Lead Time 6 Weeks
