SN74HC540NE4
RoHS
/
Package PDIP
Category Integrated Circuits (ICs) / Logic - Buffers, Drivers, Receivers, Transceivers
Description
Rail/Tube Not Qualified Nickel/Palladium/Gold (Ni/Pd/Au) HC/UH logic driver -7.8mA 150ns 5.08mm 5V
PDF
/
Inventory: 6373
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Supply Chain
Lifecycle Status ACTIVE (Last Updated: 1 week ago)
Physical
Mount Through Hole
Package / Case PDIP
Number of Pins 20
Technical
Packaging Rail/Tube
JESD-609 Code e4
Pbfree Code yes
Number of Terminations 20
ECCN Code EAR99
Terminal Finish Nickel/Palladium/Gold (Ni/Pd/Au)
Max Operating Temperature 85°C
Min Operating Temperature -40°C
Subcategory Bus Driver/Transceiver
Technology CMOS
Terminal Position DUAL
Peak Reflow Temperature (Cel) NOT SPECIFIED
Number of Functions 1
Supply Voltage 5V
Terminal Pitch 2.54mm
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Pin Count 20
Qualification Status Not Qualified
Operating Supply Voltage 5V
Number of Elements 1
Polarity Inverting
Temperature Grade INDUSTRIAL
Number of Channels 8
Max Supply Voltage 6V
Min Supply Voltage 2V
Load Capacitance 50pF
Number of Ports 2
Number of Bits 8
Propagation Delay 26 ns
Quiescent Current 8μA
Turn On Delay Time 150 ns
Family HC/UH
Logic Function Buffer, Inverter
Output Characteristics 3-STATE
Logic IC Type BUS DRIVER
Max I(ol) 0.006 A
Prop. Delay@Nom-Sup 25 ns
High Level Output Current -7.8mA
Low Level Output Current 7.8mA
Control Type ENABLE LOW
Count Direction UNIDIRECTIONAL
Dimensions
Height 5.08mm
Length 24.33mm
Width 6.35mm
Thickness 4.57mm
Compliance
RoHS Status RoHS Compliant
Lead Free Lead Free
