SN74BCT540ADW
RoHS
RoHS compliant
RoHS compliantPackage 20-SOIC (0.295, 7.50mm Width)
Category Integrated Circuits (ICs) / Logic - Buffers, Drivers, Receivers, Transceivers
Description
74BCT540 Tube WITH DUAL OUTPUT ENABLE Nickel/Palladium/Gold (Ni/Pd/Au) logic buffer 15mA 64mA 11.3ns 2.65mm 5V
PDF
/
Buying Options
Total Price: USD $10.07
Unit Price: USD $10.067317
≥1 USD $10.067317
≥200 USD $3.896687
≥500 USD $3.758833
≥1000 USD $3.691875
Inventory: 1105
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Lead Free
RoHS Status ROHS3 Compliant
REACH SVHC No SVHC
Radiation Hardening No
Dimensions
Thickness 2.35mm
Width 7.5mm
Length 12.8mm
Height 2.65mm
Technical
Translation N/A
Count Direction UNIDIRECTIONAL
Control Type ENABLE LOW
Prop. Delay@Nom-Sup 6.9 ns
Max I(ol) 0.064 A
Logic Type Buffer, Inverting
Current - Output High, Low 15mA 64mA
Logic Function Buffer, Inverter
Family BCT/FBT
Turn On Delay Time 11.3 ns
Propagation Delay 5.8 ns
Number of Bits 8
Number of Ports 2
Load Capacitance 50pF
Number of Channels 8
Power Supplies 5V
Polarity Inverting
Number of Elements 1
Operating Supply Voltage 5V
Output Type 3-State
Number of Outputs 8
Pin Count 20
Base Part Number 74BCT540
Supply Voltage 5V
Number of Functions 1
Peak Reflow Temperature (Cel) 260
Terminal Form GULL WING
Terminal Position DUAL
Voltage - Supply 4.5V~5.5V
Technology BICMOS
Subcategory Bus Driver/Transceivers
Additional Feature WITH DUAL OUTPUT ENABLE
Terminal Finish Nickel/Palladium/Gold (Ni/Pd/Au)
Termination SMD/SMT
Number of Terminations 20
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Pbfree Code yes
JESD-609 Code e4
Series 74BCT
Packaging Tube
Operating Temperature 0°C~70°C TA
Physical
Number of Pins 20
Package / Case 20-SOIC (0.295, 7.50mm Width)
Mounting Type Surface Mount
Mount Surface Mount
Supply Chain
Lifecycle Status ACTIVE (Last Updated: 1 week ago)
Factory Lead Time 6 Weeks
