SN74BCT2245DBRE4
RoHS
RoHS compliant
RoHS compliantPackage 20-SSOP (0.209, 5.30mm Width)
Category Integrated Circuits (ICs) / Logic - Buffers, Drivers, Receivers, Transceivers
Description
ROHS3Compliant BIDIRECTIONAL DUAL BICMOS Logic Transceiver, Non-Inverting 0C~70C TA 5V 2mm 7.1ns
PDF
/
Inventory: 1878
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Physical
Mount Surface Mount
Mounting Type Surface Mount
Package / Case 20-SSOP (0.209, 5.30mm Width)
Number of Pins 20
Technical
Operating Temperature 0?°C~70?°C TA
Packaging Tape & Reel (TR)
Series 74BCT
Pbfree Code yes
Part Status Obsolete
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 20
Subcategory Bus Driver/Transceivers
Packing Method TAPE AND REEL
Technology BICMOS
Voltage - Supply 4.5V~5.5V
Terminal Position DUAL
Terminal Form GULL WING
Peak Reflow Temperature (Cel) NOT SPECIFIED
Number of Functions 1
Supply Voltage 5V
Terminal Pitch 0.65mm
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Base Part Number 74BCT2245
Pin Count 20
Qualification Status Not Qualified
Output Type 3-State
Number of Elements 1
Polarity Non-Inverting
Supply Voltage-Max (Vsup) 5.5V
Power Supplies 5V
Supply Voltage-Min (Vsup) 4.5V
Number of Ports 2
Propagation Delay 7.1 ns
Family BCT/FBT
Logic Function Inverting, Transceiver
Current - Output High, Low 3mA 24mA; 12mA 12mA
Logic Type Transceiver, Non-Inverting
Number of Bits per Element 8
Control Type COMMON CONTROL
Count Direction BIDIRECTIONAL
Translation N/A
Dimensions
Height Seated (Max) 2mm
Length 7.2mm
Width 5.3mm
Compliance
RoHS Status ROHS3 Compliant
