SN74AS652NT
RoHS
RoHS compliant
RoHS compliantPackage 24-DIP (0.300, 7.62mm)
Category Integrated Circuits (ICs) / Logic - Buffers, Drivers, Receivers, Transceivers
Description
Bidirectional ROHS3Compliant Lead Free POSITIVE EDGE Logic Transceiver, Non-Inverting 0C~70C TA 50pF 5V 2.54mm
PDF
/
Buying Options
Total Price: USD $5.67
Unit Price: USD $5.67055
≥1 USD $5.67055
≥10 USD $4.65215
≥100 USD $4.5068
≥500 USD $4.36145
≥1000 USD $4.2161
Inventory: 1357
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Lead Free
RoHS Status ROHS3 Compliant
Radiation Hardening No
Dimensions
Width 7.62mm
Technical
Translation N/A
Control Type INDEPENDENT CONTROL
Trigger Type POSITIVE EDGE
Logic Type Transceiver, Non-Inverting
Current - Output High, Low 15mA 48mA
Direction Bidirectional
Logic Function Inverting, Transceiver
Family AS
Turn On Delay Time 16 ns
Quiescent Current 52mA
Propagation Delay 9 ns
Number of Bits 8
Number of Ports 2
Load Capacitance 50pF
Number of Channels 8
Power Supplies 5V
Polarity Non-Inverting
Number of Elements 1
Operating Supply Voltage 5V
Output Type 3-State
Pin Count 24
Base Part Number 74AS652
Terminal Pitch 2.54mm
Supply Voltage 5V
Number of Functions 1
Terminal Position DUAL
Voltage - Supply 4.5V~5.5V
Technology TTL
Subcategory Bus Driver/Transceivers
Additional Feature SELECT INPUT FOR MULTIPLEXED TRANSMISSION OF REGISTERED/REAL TIME DATA
Terminal Finish Nickel/Palladium/Gold (Ni/Pd/Au)
ECCN Code EAR99
Number of Terminations 24
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Obsolete
Pbfree Code yes
JESD-609 Code e4
Series 74AS
Packaging Tube
Operating Temperature 0°C~70°C TA
Physical
Weight 1.753503g
Number of Pins 24
Package / Case 24-DIP (0.300, 7.62mm)
Mounting Type Through Hole
Mount Through Hole
