SN74ALS541-1DWR
RoHS
RoHS compliant
RoHS compliantPackage 20-SOIC (0.295, 7.50mm Width)
Category Integrated Circuits (ICs) / Logic - Buffers, Drivers, Receivers, Transceivers
Description
ROHS3Compliant DUAL TTL ENABLE LOW Logic Buffer, Non-Inverting 0C~70C TA 50pF 5V 2.65mm
PDF
/
Buying Options
Total Price: USD $137.51
Unit Price: USD $137.511211
≥1 USD $137.511211
≥10 USD $129.727555
≥100 USD $122.384484
≥500 USD $115.457062
≥1000 USD $108.921753
Inventory: 1269
Minimum: 1
-
+
Technical Details
Physical
Mount Surface Mount
Mounting Type Surface Mount
Package / Case 20-SOIC (0.295, 7.50mm Width)
Number of Pins 20
Technical
Operating Temperature 0°C~70°C TA
Packaging Tape & Reel (TR)
Series 74ALS
Pbfree Code yes
Part Status Obsolete
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 20
Additional Feature WITH DUAL OUTPUT ENABLE
Subcategory Bus Driver/Transceivers
Packing Method TAPE AND REEL
Technology TTL
Voltage - Supply 4.5V~5.5V
Terminal Position DUAL
Terminal Form GULL WING
Peak Reflow Temperature (Cel) NOT SPECIFIED
Number of Functions 1
Supply Voltage 5V
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Base Part Number 74ALS541
Pin Count 20
Qualification Status Not Qualified
Output Type 3-State
Number of Elements 1
Polarity Non-Inverting
Supply Voltage-Max (Vsup) 5.5V
Power Supplies 5V
Supply Voltage-Min (Vsup) 4.5V
Load Capacitance 50pF
Number of Ports 2
Number of Bits 8
Propagation Delay 14 ns
Family ALS
Logic Function Buffer, Inverting
Current - Output High, Low 15mA 48mA
Logic Type Buffer, Non-Inverting
Control Type ENABLE LOW
Power Supply Current-Max (ICC) 25mA
Number of Output Lines 8
Dimensions
Height Seated (Max) 2.65mm
Width 7.5mm
Compliance
RoHS Status ROHS3 Compliant
