SN74AHC126DGVR
RoHS
RoHS compliant
RoHS compliantPackage 14-TFSOP (0.173, 4.40mm Width)
Category Integrated Circuits (ICs) / Logic - Buffers, Drivers, Receivers, Transceivers
Description
74AHC126 Cut Tape (CT) Not Qualified Nickel/Palladium/Gold (Ni/Pd/Au) logic driver 8mA 8mA 15ns 1.2mm 3.3V
PDF
/
Buying Options
Total Price: USD $0.29
Unit Price: USD $0.2904
≥1 USD $0.2904
≥10 USD $0.2464
≥100 USD $0.229504
≥500 USD $0.183656
≥1000 USD $0.170579
≥3000 USD $0.14432
Inventory: 1166
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 6 Weeks
Lifecycle Status ACTIVE (Last Updated: 3 days ago)
Physical
Mount Surface Mount
Mounting Type Surface Mount
Package / Case 14-TFSOP (0.173, 4.40mm Width)
Number of Pins 14
Technical
Operating Temperature -40°C~85°C TA
Packaging Cut Tape (CT)
Series 74AHC
JESD-609 Code e4
Pbfree Code yes
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 14
ECCN Code EAR99
Terminal Finish Nickel/Palladium/Gold (Ni/Pd/Au)
Subcategory Bus Driver/Transceivers
Packing Method TR
Technology CMOS
Voltage - Supply 2V~5.5V
Terminal Position DUAL
Terminal Form GULL WING
Peak Reflow Temperature (Cel) 260
Number of Functions 4
Supply Voltage 3.3V
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Base Part Number 74AHC126
Pin Count 14
Qualification Status Not Qualified
Output Type 3-State
Polarity Non-Inverting
Supply Voltage-Max (Vsup) 5.5V
Power Supplies 2/5.5V
Supply Voltage-Min (Vsup) 2V
Number of Channels 4
Load Capacitance 50pF
Number of Ports 2
Propagation Delay 11.5 ns
Quiescent Current 4μA
Turn On Delay Time 15 ns
Family AHC/VHC/H/U/V
Logic Function Buffer, Inverting
Current - Output High, Low 8mA 8mA
Logic Type Buffer, Non-Inverting
Max I(ol) 0.008 A
Number of Bits per Element 1
Prop. Delay@Nom-Sup 8.5 ns
Control Type ENABLE HIGH
Number of Output Lines 4
Count Direction UNIDIRECTIONAL
Dimensions
Height 1.2mm
Length 3.6mm
Width 4.4mm
Thickness 1.05mm
Compliance
RoHS Status ROHS3 Compliant
Lead Free Lead Free
