SN74ACT244MDWREP
RoHS
RoHS compliant
RoHS compliantPackage 20-SOIC (0.295, 7.50mm Width)
Category Integrated Circuits (ICs) / Logic - Buffers, Drivers, Receivers, Transceivers
Description
74ACT244 Tape & Reel (TR) Nickel/Palladium/Gold (Ni/Pd/Au) 74ACT logic receiver 24mA 24mA 11.5ns 2.65mm 5V
PDF
/
Buying Options
Total Price: USD $2.59
Unit Price: USD $2.5872
≥1 USD $2.5872
≥10 USD $2.32672
≥100 USD $2.199648
≥500 USD $1.906432
≥1000 USD $1.808717
≥3000 USD $1.622949
Inventory: 233
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Lead Free
RoHS Status ROHS3 Compliant
Radiation Hardening No
Dimensions
Thickness 2.35mm
Width 7.5mm
Length 12.8mm
Height 2.65mm
Technical
Translation N/A
Count Direction UNIDIRECTIONAL
Number of Input Lines 8
Control Type ENABLE LOW
Prop. Delay@Nom-Sup 10 ns
Number of Bits per Element 4
Logic Type Buffer, Non-Inverting
Current - Output High, Low 24mA 24mA
Logic Function Buffer, Inverting
Family ACT
Turn On Delay Time 11.5 ns
Quiescent Current 4μA
Propagation Delay 9 ns
Number of Ports 2
Load Capacitance 50pF
Power Supplies 5V
Polarity Non-Inverting
Number of Elements 2
Operating Supply Voltage 5V
Output Type 3-State
Pin Count 20
Base Part Number 74ACT244
Supply Voltage 5V
Number of Functions 2
Peak Reflow Temperature (Cel) 260
Terminal Form GULL WING
Terminal Position DUAL
Voltage - Supply 4.5V~5.5V
Technology CMOS
Packing Method TR
Subcategory Bus Driver/Transceivers
Terminal Finish Nickel/Palladium/Gold (Ni/Pd/Au)
ECCN Code EAR99
Number of Terminations 20
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Pbfree Code yes
JESD-609 Code e4
Series 74ACT
Packaging Tape & Reel (TR)
Operating Temperature -55°C~125°C TA
Physical
Number of Pins 20
Package / Case 20-SOIC (0.295, 7.50mm Width)
Mounting Type Surface Mount
Mount Surface Mount
Supply Chain
Lifecycle Status ACTIVE (Last Updated: 6 days ago)
Factory Lead Time 6 Weeks
