SN7417NE4
RoHS
/
Package PDIP
Category Integrated Circuits (ICs) / Logic - Buffers, Drivers, Receivers, Transceivers
Description
PDIP Not Qualified Nickel/Palladium/Gold (Ni/Pd/Au) TTL/H/L logic receiver -250muA 26ns 4.57mm 145mW
PDF
/
Inventory: 5364
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
Lead Free Lead Free
RoHS Status RoHS Compliant
Dimensions
Width 6.35mm
Length 19.3mm
Height 4.57mm
Technical
Number of Output Lines 18
Schmitt Trigger NO
Low Level Output Current 40mA
High Level Output Current -250μA
Number of Bits per Element 1
Max I(ol) 0.04 A
Output Characteristics OPEN-COLLECTOR
Logic Function Buffer, Inverting
Family TTL/H/L
Turn On Delay Time 26 ns
Propagation Delay 26 ns
Load Capacitance 50pF
Power Dissipation-Max 145mW
Min Supply Voltage 4.75V
Max Supply Voltage 5.25V
Temperature Grade COMMERCIAL
Power Supplies 5V
Polarity Non-Inverting
Number of Elements 6
Operating Supply Voltage 5V
Qualification Status Not Qualified
Pin Count 14
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Terminal Pitch 2.54mm
Supply Voltage 5V
Number of Functions 6
Peak Reflow Temperature (Cel) NOT SPECIFIED
Terminal Position DUAL
Technology TTL
Packing Method TUBE
Subcategory Gates
Min Operating Temperature 0°C
Max Operating Temperature 70°C
Terminal Finish Nickel/Palladium/Gold (Ni/Pd/Au)
Number of Terminations 14
Pbfree Code yes
JESD-609 Code e4
Physical
Number of Pins 14
Package / Case PDIP
Mount Through Hole
