CY74FCT646CTQCT
RoHS
RoHS compliant
RoHS compliantPackage 24-SSOP (0.154, 3.90mm Width)
Category Integrated Circuits (ICs) / Logic - Buffers, Drivers, Receivers, Transceivers
Description
Bidirectional ROHS3Compliant Contains Lead POSITIVE EDGE Logic Transceiver, Non-Inverting -40C~85C TA 5V 0.635mm 7.8ns
PDF
/
Buying Options
Total Price: USD $4.36
Unit Price: USD $4.3605
≥1 USD $4.3605
≥10 USD $3.5777
≥100 USD $3.46655
≥500 USD $3.35445
≥1000 USD $3.24235
Inventory: 1508
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Contains Lead
RoHS Status ROHS3 Compliant
Radiation Hardening No
Dimensions
Width 3.9mm
Technical
Translation N/A
Control Type INDEPENDENT CONTROL
Trigger Type POSITIVE EDGE
Prop. Delay@Nom-Sup 5.4 ns
Max I(ol) 0.064 A
Logic Type Transceiver, Non-Inverting
Current - Output High, Low 32mA 64mA
Direction Bidirectional
Logic Function Inverting, Transceiver
Family FCT
Turn On Delay Time 7.8 ns
Propagation Delay 5.7 ns
Number of Bits 8
Number of Ports 2
Number of Channels 8
Power Supplies 5V
Polarity Non-Inverting
Number of Elements 1
Operating Supply Voltage 5V
Output Type 3-State
Pin Count 24
Base Part Number 74FCT646
Terminal Pitch 0.635mm
Supply Voltage 5V
Number of Functions 1
Peak Reflow Temperature (Cel) 260
Terminal Form GULL WING
Terminal Position DUAL
Voltage - Supply 4.75V~5.25V
Technology CMOS
Packing Method TAPE AND REEL
Subcategory Bus Driver/Transceivers
Terminal Finish Nickel/Palladium/Gold (Ni/Pd/Au)
Number of Terminations 24
Moisture Sensitivity Level (MSL) 2 (1 Year)
Part Status Discontinued
Pbfree Code yes
JESD-609 Code e4
Series 74FCT
Packaging Tape & Reel (TR)
Operating Temperature -40°C~85°C TA
Physical
Weight 129.500622mg
Number of Pins 24
Package / Case 24-SSOP (0.154, 3.90mm Width)
Mounting Type Surface Mount
Mount Surface Mount
