CY74FCT244TSOCT

Texas Instruments
RoHS
RoHS RoHS compliant
Package 20-SOIC (0.295, 7.50mm Width)
Category Integrated Circuits (ICs) / Logic - Buffers, Drivers, Receivers, Transceivers
Description 74FCT244 Cut Tape (CT) 74FCT FCT logic receiver 32mA 64mA 8ns 2.65mm 5V
PDF
/
Buying Options
Total Price: USD $0.81
Unit Price: USD $0.8096
≥1 USD $0.8096
≥10 USD $0.72336
Inventory: 76
Minimum: 1
-
+

Technical Details

Supply Chain

Factory Lead Time 6 Weeks
Lifecycle Status ACTIVE (Last Updated: 3 days ago)

Physical

Contact Plating Gold
Mount Surface Mount
Mounting Type Surface Mount
Package / Case 20-SOIC (0.295, 7.50mm Width)
Number of Pins 20

Technical

Operating Temperature -40°C~85°C TA
Packaging Cut Tape (CT)
Series 74FCT
JESD-609 Code e4
Pbfree Code yes
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 20
ECCN Code EAR99
Subcategory Bus Driver/Transceivers
Packing Method TR
Technology CMOS
Voltage - Supply 4.75V~5.25V
Terminal Position DUAL
Terminal Form GULL WING
Peak Reflow Temperature (Cel) 260
Number of Functions 2
Supply Voltage 5V
Base Part Number 74FCT244
Pin Count 20
Output Type 3-State
Operating Supply Voltage 5V
Number of Elements 2
Polarity Non-Inverting
Power Supplies 5V
Load Capacitance 50pF
Number of Ports 2
Propagation Delay 6.5 ns
Quiescent Current 100μA
Turn On Delay Time 8 ns
Family FCT
Logic Function Buffer, Inverting
Current - Output High, Low 32mA 64mA
Logic Type Buffer, Non-Inverting
Number of Bits per Element 4
Control Type ENABLE LOW
Number of Input Lines 8
Number of Output Lines 3
Count Direction UNIDIRECTIONAL

Dimensions

Height 2.65mm
Length 12.8mm
Width 7.5mm
Thickness 2.35mm

Compliance

Radiation Hardening No
RoHS Status ROHS3 Compliant
Lead Free Lead Free
