CD74HCT126M96E4
RoHS
RoHS compliant
RoHS compliantPackage 14-SOIC (0.154, 3.90mm Width)
Category Integrated Circuits (ICs) / Logic - Buffers, Drivers, Receivers, Transceivers
Description
74HCT126 Tape & Reel (TR) Not Qualified 74HCT logic receiver 6mA 6mA 42ns 1.75mm 5V
PDF
/
Inventory: 6044
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
Lead Free Lead Free
RoHS Status ROHS3 Compliant
Dimensions
Thickness 1.58mm
Width 3.91mm
Length 8.65mm
Height 1.75mm
Technical
Count Direction UNIDIRECTIONAL
Control Type ENABLE HIGH
Prop. Delay@Nom-Sup 36 ns
Number of Bits per Element 1
Max I(ol) 0.006 A
Logic Type Buffer, Non-Inverting
Current - Output High, Low 6mA 6mA
Logic Function Buffer, Inverting
Family HCT
Turn On Delay Time 42 ns
Quiescent Current 8μA
Propagation Delay 24 ns
Number of Ports 2
Load Capacitance 50pF
Number of Channels 4
Power Supplies 5V
Polarity Non-Inverting
Operating Supply Voltage 5V
Output Type 3-State
Qualification Status Not Qualified
Number of Outputs 4
Pin Count 14
Base Part Number 74HCT126
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Supply Voltage 5V
Number of Functions 4
Peak Reflow Temperature (Cel) 260
Terminal Form GULL WING
Terminal Position DUAL
Voltage - Supply 4.5V~5.5V
Technology CMOS
Packing Method TR
Subcategory Bus Driver/Transceivers
Number of Terminations 14
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Pbfree Code yes
JESD-609 Code e4
Series 74HCT
Packaging Tape & Reel (TR)
Operating Temperature -55°C~125°C TA
Physical
Number of Pins 14
Package / Case 14-SOIC (0.154, 3.90mm Width)
Mounting Type Surface Mount
Mount Surface Mount
Contact Plating Gold
Supply Chain
Lifecycle Status ACTIVE (Last Updated: 1 week ago)
Factory Lead Time 6 Weeks
