CD74HC4050MG4
RoHS
/
Package SOIC
Category Integrated Circuits (ICs) / Logic - Buffers, Drivers, Receivers, Transceivers
Description
SOIC CMOS-TTL LEVEL TRANSLATOR HC/UH Buffer Inverting logic receiver -5.2mA 130ns 1.58mm 4.5V
PDF
/
Inventory: 8771
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
Lead Free Lead Free
RoHS Status RoHS Compliant
Radiation Hardening No
Dimensions
Width 3.91mm
Length 9.9mm
Height 1.58mm
Technical
Schmitt Trigger NO
Low Level Output Current 5.2mA
High Level Output Current -5.2mA
Number of Bits per Element 1
Max I(ol) 0.004 A
Logic Function Buffer, Inverting
Family HC/UH
Turn On Delay Time 130 ns
Quiescent Current 2μA
Propagation Delay 85 ns
Load Capacitance 50pF
Min Supply Voltage 2V
Max Supply Voltage 6V
Temperature Grade MILITARY
Polarity Non-Inverting
Number of Elements 6
Pin Count 16
Supply Voltage 4.5V
Number of Functions 6
Peak Reflow Temperature (Cel) 260
Terminal Form GULL WING
Terminal Position DUAL
Technology CMOS
Packing Method TUBE
Subcategory Gates
Additional Feature CMOS-TTL LEVEL TRANSLATOR
Min Operating Temperature -55°C
Max Operating Temperature 125°C
Number of Terminations 16
Moisture Sensitivity Level (MSL) 1
JESD-609 Code e4
Physical
Number of Pins 16
Package / Case SOIC
Mount Surface Mount
Contact Plating Gold
