CD74ACT244SM
RoHS
/
Package SSOP
Category Integrated Circuits (ICs) / Logic - Buffers, Drivers, Receivers, Transceivers
Description
RoHS Compliant TRUE DUAL CMOS logic driver 85C 50pF 5V 2mm
PDF
/
Buying Options
Total Price: USD $0.08
Unit Price: USD $0.08454
≥1 USD $0.08454
≥200 USD $0.032716
≥500 USD $0.031566
≥1000 USD $0.030998
Inventory: 1436
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status RoHS Compliant
Dimensions
Width 5.3mm
Length 7.2mm
Height Seated (Max) 2mm
Technical
Control Type ENABLE LOW
Propagation Delay (tpd) 93 ns
Prop. Delay@Nom-Sup 9.6 ns
Max I(ol) 0.024 A
Logic IC Type BUS DRIVER
Output Polarity TRUE
Output Characteristics 3-STATE
Logic Function Buffer
Family ACT
Number of Bits 4
Number of Ports 2
Load Capacitance 50pF
Supply Voltage-Min (Vsup) 4.5V
Temperature Grade INDUSTRIAL
Power Supplies 5V
Supply Voltage-Max (Vsup) 5.5V
Operating Temperature (Min) -40°C
Operating Temperature (Max) 85°C
Qualification Status Not Qualified
JESD-30 Code R-PDSO-G20
Pin Count 20
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Terminal Pitch 0.65mm
Supply Voltage 5V
Number of Functions 2
Peak Reflow Temperature (Cel) NOT SPECIFIED
Terminal Form GULL WING
Terminal Position DUAL
Technology CMOS
Subcategory Bus Driver/Transceivers
HTS Code 8542.39.00.01
Additional Feature OUTPUT ENABLE ACTIVE HIGH FOR ONE FUNCTION
Number of Terminations 20
Physical
Surface Mount YES
Package / Case SSOP
