CD54AC245F3A
RoHS
/
Package CDIP
Category Integrated Circuits (ICs) / Logic - Buffers, Drivers, Receivers, Transceivers
Description
Bidirectional RoHS Compliant Contains Lead DUAL logic receiver 125C 50pF 3.3V 5.08mm
PDF
/
Buying Options
Total Price: USD $14.73
Unit Price: USD $14.7326
≥1 USD $14.7326
≥10 USD $12.08875
≥100 USD $11.71065
≥500 USD $11.33255
≥1000 USD $10.9554
Inventory: 1263
Minimum: 1
-
+
Technical Details
Supply Chain
Lifecycle Status ACTIVE (Last Updated: 5 days ago)
Physical
Mount Through Hole
Package / Case CDIP
Number of Pins 20
Technical
Number of Terminations 20
ECCN Code EAR99
Max Operating Temperature 125°C
Min Operating Temperature -55°C
Additional Feature WITH DIRECTION CONTROL
Packing Method TUBE
Technology CMOS
Terminal Position DUAL
Number of Functions 1
Supply Voltage 3.3V
Terminal Pitch 2.54mm
Pin Count 20
Number of Elements 1
Polarity Non-Inverting
Power Supplies 3.3/5V
Temperature Grade MILITARY
Max Supply Voltage 5.5V
Min Supply Voltage 1.5V
Load Capacitance 50pF
Number of Ports 2
Number of Bits 8
Propagation Delay 175 ns
Quiescent Current 8μA
Turn On Delay Time 175 ns
Family AC
Logic Function Transceiver
Direction Bidirectional
Output Characteristics 3-STATE
Max I(ol) 0.024 A
High Level Output Current -24mA
Low Level Output Current 24mA
Control Type COMMON CONTROL
Schmitt Trigger No
Translation N/A
Dimensions
Height 5.08mm
Length 24.2mm
Width 6.92mm
Thickness 4.57mm
Compliance
Radiation Hardening No
RoHS Status RoHS Compliant
Lead Free Contains Lead
