CD4010BEE4

Texas Instruments
RoHS
/
Package PDIP
Category Integrated Circuits (ICs) / Logic - Buffers, Drivers, Receivers, Transceivers
Description Rail/Tube DUAL SUPPLY HIGH TO LOW VOLTAGE TRANSLATOR Buffer Non-Inverting logic receiver -1.65mA 200ns 5.08mm 5V
PDF
/
Inventory: 5850
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and contact information to get a quote.
Quotation Consultation
Is there anything else we can help you solve?
Inquiry

Technical Details

Physical

Contact Plating Gold
Mount Through Hole
Package / Case PDIP
Number of Pins 16

Technical

Packaging Rail/Tube
JESD-609 Code e4
Pbfree Code yes
Number of Terminations 16
Max Operating Temperature 125°C
Min Operating Temperature -55°C
Additional Feature DUAL SUPPLY HIGH TO LOW VOLTAGE TRANSLATOR
Subcategory Gates
Technology CMOS
Terminal Position DUAL
Number of Functions 6
Supply Voltage 5V
Terminal Pitch 2.54mm
Pin Count 16
Number of Elements 6
Polarity Non-Inverting
Temperature Grade MILITARY
Max Supply Voltage 18V
Min Supply Voltage 3V
Load Capacitance 50pF
Propagation Delay 70 ns
Quiescent Current 20μA
Turn On Delay Time 200 ns
Logic Function Buffer
Output Characteristics OPEN-DRAIN
Number of Bits per Element 1
High Level Output Current -1.65mA
Low Level Output Current 30mA
Schmitt Trigger NO

Dimensions

Height Seated (Max) 5.08mm

Compliance

Radiation Hardening No
RoHS Status RoHS Compliant
Lead Free Lead Free
