AM26LS33AMWB
RoHS
/
Package /
Category Integrated Circuits (ICs) / Logic - Buffers, Drivers, Receivers, Transceivers
Description
RoHS Compliant Contains Lead TRUE DIFFERENTIAL SCHMITT TRIGGER logic buffer 125C 10Mbps 5V 2.03mm
PDF
/
Buying Options
Total Price: USD $20.49
Unit Price: USD $20.4864
≥1 USD $20.4864
Inventory: 35
Minimum: 1
-
+
Technical Details
Supply Chain
Lifecycle Status ACTIVE (Last Updated: 6 days ago)
Physical
Mount Surface Mount
Number of Pins 16
Technical
Packaging Rail/Tube
Number of Terminations 16
ECCN Code EAR99
Max Operating Temperature 125°C
Min Operating Temperature -55°C
Technology BIPOLAR
Terminal Position DUAL
Terminal Form FLAT
Number of Functions 4
Supply Voltage 5V
Terminal Pitch 1.27mm
Pin Count 16
Operating Supply Voltage 5V
Power Supplies 5V
Temperature Grade MILITARY
Max Supply Voltage 5.5V
Min Supply Voltage 4.5V
Nominal Supply Current 70mA
Max Supply Current 70mA
Logic Function Receiver
Data Rate 10 Mbps
Output Characteristics 3-STATE
Differential Output NO
Output Polarity TRUE
Input Characteristics DIFFERENTIAL SCHMITT TRIGGER
Screening Level MIL-STD-883 Class B
ESD Protection No
Receive Delay-Max 35 ns
Supply Voltage1-Nom 5V
Output Low Current-Max 0.00002A
Number of Receivers 4
Dimensions
Height 2.03mm
Length 10.3mm
Width 6.73mm
Thickness 1.65mm
Compliance
RoHS Status RoHS Compliant
Lead Free Contains Lead
