74ACT11245PWE4
RoHS
RoHS compliant
RoHS compliantPackage 24-TSSOP (0.173, 4.40mm Width)
Category Integrated Circuits (ICs) / Logic - Buffers, Drivers, Receivers, Transceivers
Description
74ACT11245 Tube WITH DIRECTION CONTROL Not Qualified logic buffer 24mA 24mA 9.2ns 0.65mm 700mW
PDF
/
Inventory: 9086
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Dimensions
Width 4.4mm
Technical
Translation N/A
Count Direction BIDIRECTIONAL
Control Type COMMON CONTROL
Number of Bits per Element 8
Logic Type Transceiver, Non-Inverting
Current - Output High, Low 24mA 24mA
Logic Function Inverting, Transceiver
Family ACT
Propagation Delay 9.2 ns
Number of Ports 2
Supply Voltage-Min (Vsup) 4.5V
Power Supplies 5V
Supply Voltage-Max (Vsup) 5.5V
Polarity Non-Inverting
Number of Elements 1
Output Type 3-State
Qualification Status Not Qualified
Pin Count 24
Base Part Number 74ACT11245
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Terminal Pitch 0.65mm
Supply Voltage 5V
Number of Functions 1
Peak Reflow Temperature (Cel) NOT SPECIFIED
Terminal Form GULL WING
Terminal Position DUAL
Voltage - Supply 4.5V~5.5V
Technology CMOS
Max Power Dissipation 700mW
Subcategory Bus Driver/Transceivers
Additional Feature WITH DIRECTION CONTROL
Number of Terminations 24
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Obsolete
Pbfree Code yes
Series 74ACT
Packaging Tube
Operating Temperature -40°C~85°C TA
Physical
Number of Pins 24
Package / Case 24-TSSOP (0.173, 4.40mm Width)
Mounting Type Surface Mount
Mount Surface Mount
