74AC16244DL
RoHS
RoHS compliant
RoHS compliantPackage 48-BSSOP (0.295, 7.50mm Width)
Category Integrated Circuits (ICs) / Logic - Buffers, Drivers, Receivers, Transceivers
Description
74AC16244 Tube 74AC AC logic driver 24mA 24mA 14.6ns 2.79mm 1.2W
PDF
/
Buying Options
Total Price: USD $2.6
Unit Price: USD $2.6048
≥1 USD $2.6048
≥10 USD $2.3408
Inventory: 105
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 6 Weeks
Lifecycle Status ACTIVE (Last Updated: 1 day ago)
Physical
Contact Plating Gold
Mount Surface Mount
Mounting Type Surface Mount
Package / Case 48-BSSOP (0.295, 7.50mm Width)
Number of Pins 48
Manufacturer Package Identifier DL0048A
Technical
Operating Temperature -40°C~85°C TA
Packaging Tube
Series 74AC
JESD-609 Code e4
Pbfree Code yes
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 48
Subcategory Bus Driver/Transceivers
Max Power Dissipation 1.2W
Technology CMOS
Voltage - Supply 3V~5.5V
Terminal Position DUAL
Terminal Form GULL WING
Peak Reflow Temperature (Cel) 260
Number of Functions 4
Supply Voltage 5V
Terminal Pitch 0.635mm
Base Part Number 74AC16244
Pin Count 48
Output Type 3-State
Operating Supply Voltage 5V
Number of Elements 4
Polarity Non-Inverting
Supply Voltage-Min (Vsup) 3V
Load Capacitance 50pF
Number of Ports 2
Number of Bits 4
Propagation Delay 14.6 ns
Quiescent Current 8μA
Turn On Delay Time 14.6 ns
Family AC
Logic Function Buffer, Inverting
Current - Output High, Low 24mA 24mA
Logic Type Buffer, Non-Inverting
Prop. Delay@Nom-Sup 11.8 ns
Control Type ENABLE LOW
Power Supply Current-Max (ICC) 0.08mA
Number of Input Lines 16
Count Direction UNIDIRECTIONAL
Translation N/A
Dimensions
Height 2.79mm
Length 15.88mm
Width 7.49mm
Thickness 2.59mm
Compliance
Radiation Hardening No
REACH SVHC No SVHC
RoHS Status ROHS3 Compliant
Lead Free Lead Free
