74AC11245DW
RoHS
RoHS compliant
RoHS compliantPackage 24-SOIC (0.295, 7.50mm Width)
Category Integrated Circuits (ICs) / Logic - Buffers, Drivers, Receivers, Transceivers
Description
74AC11245 Tube WITH DIRECTION CONTROL 74AC logic receiver 24mA 24mA 11.2ns 2.65mm 1.7W
PDF
/
Buying Options
Total Price: USD $31.72
Unit Price: USD $31.7167
≥1 USD $31.7167
≥10 USD $26.02335
≥100 USD $25.21015
≥500 USD $24.39695
≥1000 USD $23.58375
Inventory: 1170
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Lead Free
RoHS Status ROHS3 Compliant
REACH SVHC No SVHC
Radiation Hardening No
Dimensions
Thickness 2.35mm
Width 7.5mm
Length 15.4mm
Height 2.65mm
Technical
Translation N/A
Schmitt Trigger No
Control Type COMMON CONTROL
Prop. Delay@Nom-Sup 9.5 ns
Logic Type Transceiver, Non-Inverting
Current - Output High, Low 24mA 24mA
Direction Bidirectional
Logic Function Inverting, Transceiver
Family AC
Turn On Delay Time 11.2 ns
Quiescent Current 8μA
Propagation Delay 15.9 ns
Number of Bits 8
Number of Ports 2
Load Capacitance 50pF
Number of Channels 8
Supply Voltage-Min (Vsup) 3V
Polarity Non-Inverting
Number of Elements 1
Operating Supply Voltage 5V
Output Type 3-State
Pin Count 24
Base Part Number 74AC11245
Supply Voltage 5V
Number of Functions 1
Peak Reflow Temperature (Cel) 260
Terminal Form GULL WING
Terminal Position DUAL
Voltage - Supply 3V~5.5V
Technology CMOS
Max Power Dissipation 1.7W
Subcategory Bus Driver/Transceivers
Additional Feature WITH DIRECTION CONTROL
ECCN Code EAR99
Number of Terminations 24
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Pbfree Code yes
JESD-609 Code e4
Series 74AC
Packaging Tube
Operating Temperature -40°C~85°C TA
Physical
Weight 624.398247mg
Number of Pins 24
Package / Case 24-SOIC (0.295, 7.50mm Width)
Mounting Type Surface Mount
Mount Surface Mount
Contact Plating Gold
Supply Chain
Lifecycle Status ACTIVE (Last Updated: 3 days ago)
Factory Lead Time 6 Weeks
