AM29C863APC
RoHS
/
Package /
Category Integrated Circuits (ICs) / Logic - Buffers, Drivers, Receivers, Transceivers
Description
Non-RoHS Compliant TRUE BIDIRECTIONAL DUAL logic driver 70C 300pF 5V 5.08mm
PDF
/
Buying Options
Total Price: USD $2.88
Unit Price: USD $2.8776
≥1 USD $2.8776
Inventory: 1233
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status Non-RoHS Compliant
Dimensions
Width 7.62mm
Length 30.734mm
Height Seated (Max) 5.08mm
Technical
Translation N/A
Count Direction BIDIRECTIONAL
Control Type INDEPENDENT CONTROL
Propagation Delay (tpd) 15.5 ns
Prop. Delay@Nom-Sup 9 ns
Max I(ol) 0.048 A
Logic IC Type BUS TRANSCEIVER
Output Polarity TRUE
Output Characteristics 3-STATE
Family CMOS
Number of Bits 9
Number of Ports 2
Load Capacitance 300pF
Supply Voltage-Min (Vsup) 4.5V
Temperature Grade COMMERCIAL
Power Supplies 5V
Supply Voltage-Max (Vsup) 5.5V
Operating Temperature (Max) 70°C
Qualification Status Not Qualified
JESD-30 Code R-PDIP-T24
Pin Count 24
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Terminal Pitch 2.54mm
Supply Voltage 5V
Number of Functions 1
Peak Reflow Temperature (Cel) NOT SPECIFIED
Terminal Form THROUGH-HOLE
Terminal Position DUAL
Technology CMOS
Subcategory Bus Driver/Transceivers
HTS Code 8542.39.00.01
Additional Feature WITH DUAL INDEPENDENT OUTPUT ENABLE FOR EACH DIRECTION
Terminal Finish Tin/Lead (Sn/Pb)
Number of Terminations 24
Pbfree Code no
JESD-609 Code e0
Physical
Surface Mount NO
