VSP3200YG4

Texas Instruments
RoHS
RoHS RoHS compliant
Package 48-LQFP
Category Integrated Circuits (ICs) / Linear - Video Processing
Description Lead Free ROHS3Compliant GULL WING OTHER Video (Function) 85C 2B 5.3V 70mA
PDF
/
Inventory: 1495
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and contact information to get a quote.
Quotation Consultation
Is there anything else we can help you solve?
Inquiry

Technical Details

Supply Chain

Factory Lead Time 6 Weeks
Lifecycle Status ACTIVE (Last Updated: 3 days ago)

Physical

Mount Surface Mount
Mounting Type Surface Mount
Package / Case 48-LQFP
Number of Pins 48
Weight 179.991122mg

Technical

Packaging Tray
JESD-609 Code e4
Pbfree Code yes
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 48
Type CCD Signal Processor
Terminal Finish Nickel/Palladium/Gold (Ni/Pd/Au)
Max Operating Temperature 85°C
Min Operating Temperature 0°C
Applications Scanners
Subcategory Other Consumer ICs
Technology CMOS
Terminal Position QUAD
Terminal Form GULL WING
Peak Reflow Temperature (Cel) 260
Number of Functions 1
Conversion Rate 8 Msps
Number of A/D Converters 1
Sampling Rate 8 Msps
Resolution 2 B
Operating Supply Current 70mA
Min Supply Voltage 2.7V
Max Supply Voltage 5.3V
Interface Serial
Temperature Grade OTHER
Power Supplies 5V
Pin Count 48
Base Part Number VSP3200
Terminal Pitch 0.5mm

Compliance

Lead Free Lead Free
RoHS Status ROHS3 Compliant
Radiation Hardening No

Dimensions

Thickness 1.4mm
Width 7mm
Length 7mm
Height 1.6mm
