VSP2270Y/2K
RoHS
RoHS compliant
RoHS compliantPackage 48-LQFP
Category Integrated Circuits (ICs) / Linear - Video Processing
Description
ROHS3Compliant GULL WING OTHER QUAD Video (Function) 85C 1.25B 3.6V 7mm
PDF
/
Buying Options
Total Price: USD $37.05
Unit Price: USD $37.04905
≥1 USD $37.04905
≥10 USD $30.39905
≥100 USD $29.44905
≥500 USD $28.49905
≥1000 USD $27.55
Inventory: 1534
Minimum: 1
-
+
Technical Details
Physical
Mount Surface Mount
Mounting Type Surface Mount
Package / Case 48-LQFP
Number of Pins 48
Technical
Packaging Tape & Reel (TR)
Pbfree Code yes
Part Status Obsolete
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 48
Type CCD Signal Processor, 10-Bit
Max Operating Temperature 85°C
Min Operating Temperature -25°C
Applications DSC, DVC, Camera
Technology CMOS
Terminal Position QUAD
Terminal Form GULL WING
Peak Reflow Temperature (Cel) NOT SPECIFIED
Number of Functions 1
Terminal Pitch 0.5mm
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Base Part Number VSP2270
Pin Count 48
Qualification Status Not Qualified
Operating Supply Voltage 3V
Supply Voltage-Max (Vsup) 3.6V
Temperature Grade OTHER
Supply Voltage-Min (Vsup) 2.7V
Number of Channels 1
Resolution 1.25 B
Dimensions
Length 7mm
Width 7mm
Compliance
RoHS Status ROHS3 Compliant
