VSP2232Y/2K
RoHS
RoHS compliant
RoHS compliantPackage 48-LQFP
Category Integrated Circuits (ICs) / Linear - Video Processing
Description
CCD Signal Processor 10-Bit Tape & Reel (TR) VSP2232 Surface Mount video processing unit 36Msps 7mm 3.6V 1.5B
PDF
/
Buying Options
Total Price: USD $32.66
Unit Price: USD $32.6591
≥1 USD $32.6591
≥10 USD $26.7976
≥100 USD $25.9597
≥500 USD $25.12275
≥1000 USD $24.28485
Inventory: 1527
Minimum: 1
-
+
Technical Details
Physical
Mount Surface Mount
Mounting Type Surface Mount
Package / Case 48-LQFP
Number of Pins 48
Weight 179.991122mg
Technical
Packaging Tape & Reel (TR)
JESD-609 Code e4
Pbfree Code no
Part Status Obsolete
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 48
Type CCD Signal Processor, 10-Bit
Terminal Finish Nickel/Palladium/Gold (Ni/Pd/Au)
Max Operating Temperature 85°C
Min Operating Temperature -25°C
Applications Camera
Technology CMOS
Terminal Position QUAD
Terminal Form GULL WING
Peak Reflow Temperature (Cel) 260
Number of Functions 1
Terminal Pitch 0.5mm
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Base Part Number VSP2232
Pin Count 48
Qualification Status Not Qualified
Operating Supply Voltage 3V
Temperature Grade OTHER
Number of Channels 1
Interface Serial
Max Supply Voltage 3.6V
Min Supply Voltage 2.7V
Resolution 1.5 B
Sampling Rate 36 Msps
Conversion Rate 36 Msps
Dimensions
Length 7mm
Width 7mm
Compliance
RoHS Status ROHS3 Compliant
Lead Free Contains Lead
