LMH0026MHX/NOPB
RoHS
RoHS compliant
RoHS compliantPackage 20-PowerTSSOP (0.173, 4.40mm Width)
Category Integrated Circuits (ICs) / Linear - Video Processing
Description
Contains Lead ROHS3Compliant GULL WING INDUSTRIAL video processing unit 85C 330W 3.465V 6.5mm
PDF
/
Buying Options
Total Price: USD $22.9
Unit Price: USD $22.9026
≥1 USD $22.9026
≥10 USD $18.79195
≥100 USD $18.20485
≥500 USD $17.61775
≥1000 USD $17.0297
Inventory: 1278
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Contains Lead
RoHS Status ROHS3 Compliant
Radiation Hardening No
Dimensions
Width 4.4mm
Length 6.5mm
Height Seated (Max) 1.1mm
Technical
Power Consumption 330W
Supply Voltage-Min (Vsup) 3.135V
Temperature Grade INDUSTRIAL
Power Supplies 3.3V
Supply Voltage-Max (Vsup) 3.465V
Pin Count 20
Base Part Number LMH0026
Terminal Pitch 0.65mm
Number of Functions 1
Peak Reflow Temperature (Cel) 260
Terminal Form GULL WING
Terminal Position DUAL
Subcategory Other Consumer ICs
HTS Code 8542.39.00.01
Applications Digital Video
Min Operating Temperature -40°C
Max Operating Temperature 85°C
Terminal Finish Matte Tin (Sn)
Type Reclocker
ECCN Code EAR99
Number of Terminations 20
Moisture Sensitivity Level (MSL) 3 (168 Hours)
Part Status Obsolete
Pbfree Code no
JESD-609 Code e3
Packaging Tape & Reel (TR)
Physical
Number of Pins 20
Package / Case 20-PowerTSSOP (0.173, 4.40mm Width)
Mounting Type Surface Mount
Mount Surface Mount
