DS34RT5110SQX/NOPB
RoHS
RoHS compliant
RoHS compliantPackage 48-WFQFN Exposed Pad
Category Integrated Circuits (ICs) / Linear - Video Processing
Description
Lead Free ROHS3Compliant COMMERCIAL QUAD Video (Function) 70C 1.1kW 3.465V 800mum
PDF
/
Buying Options
Total Price: USD $20.13
Unit Price: USD $20.1286
≥1 USD $20.1286
≥10 USD $16.51575
≥100 USD $15.9999
≥500 USD $15.48405
≥1000 USD $14.96725
Inventory: 1444
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Lead Free
RoHS Status ROHS3 Compliant
Radiation Hardening No
Dimensions
Thickness 750μm
Width 7mm
Length 7mm
Height 800μm
Technical
Power Consumption 1.1kW
Data Rate 3.4 Gbps
Min Supply Voltage 3.135V
Max Supply Voltage 3.465V
Temperature Grade COMMERCIAL
Number of Elements 3
Operating Supply Voltage 3.3V
Pin Count 48
Base Part Number DS34RT5110
Terminal Pitch 0.5mm
Number of Functions 1
Peak Reflow Temperature (Cel) 260
Terminal Position QUAD
Subcategory Other Consumer ICs
Applications HDMI, DVI, Receivers
Min Operating Temperature 0°C
Max Operating Temperature 70°C
Type Retimer
ECCN Code EAR99
Number of Terminations 48
Moisture Sensitivity Level (MSL) 3 (168 Hours)
Part Status Not For New Designs
Pbfree Code yes
JESD-609 Code e3
Packaging Tape & Reel (TR)
Physical
Number of Pins 48
Package / Case 48-WFQFN Exposed Pad
Mounting Type Surface Mount
Mount Surface Mount
Contact Plating Tin
Supply Chain
Lifecycle Status NRND (Last Updated: 5 days ago)
