DS22EV5110SQ/NOPB

Texas Instruments
RoHS
RoHS RoHS compliant
Package 48-WFQFN Exposed Pad
Category Integrated Circuits (ICs) / Linear - Video Processing
Description Lead Free ROHS3Compliant COMMERCIAL QUAD Video (Function) 70C 1.1kW 800mum
PDF
/
Buying Options
Total Price: USD $10.47
Unit Price: USD $10.472
≥1 USD $10.472
Inventory: 993
Minimum: 1
-
+

Technical Details

Compliance

Lead Free Lead Free
RoHS Status ROHS3 Compliant
Radiation Hardening No

Dimensions

Thickness 750μm
Width 7mm
Length 7mm
Height 800μm

Technical

Number of Drivers 1
Power Consumption 1.1kW
Number of Channels 3
Temperature Grade COMMERCIAL
Pin Count 48
Base Part Number DS22EV5110
Terminal Pitch 0.5mm
Number of Functions 1
Peak Reflow Temperature (Cel) 260
Terminal Position QUAD
Subcategory Other Consumer ICs
Applications HDMI, DVI, Receivers
Min Operating Temperature 0°C
Max Operating Temperature 70°C
Terminal Finish Matte Tin (Sn)
Type Equalizer
ECCN Code EAR99
Number of Terminations 48
Moisture Sensitivity Level (MSL) 3 (168 Hours)
Part Status Not For New Designs
Pbfree Code yes
JESD-609 Code e3
Packaging Tape & Reel (TR)

Physical

Number of Pins 48
Package / Case 48-WFQFN Exposed Pad
Mounting Type Surface Mount
Mount Surface Mount

Supply Chain

Lifecycle Status NRND (Last Updated: 3 days ago)
