STVM100DS6F
RoHS
RoHS compliant
RoHS compliantPackage 8-TSSOP, 8-MSOP (0.118, 3.00mm Width)
Category Integrated Circuits (ICs) / Linear - Video Processing
Description
Calibrator Tape & Reel (TR) STVM100 Surface Mount video processing unit 3mm 3.6V 85C
PDF
/
Buying Options
Total Price: USD $1.09
Unit Price: USD $1.0912
≥1 USD $1.0912
≥10 USD $0.97768
≥100 USD $0.927872
≥500 USD $0.762256
≥1000 USD $0.712589
≥3000 USD $0.629728
Inventory: 1339
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Radiation Hardening No
Dimensions
Width 3mm
Length 3mm
Height Seated (Max) 1.1mm
Technical
Min Supply Voltage 2.25V
Max Supply Voltage 3.6V
Temperature Grade INDUSTRIAL
Pin Count 8
Base Part Number STVM100
Terminal Pitch 0.65mm
Supply Voltage 3V
Number of Functions 1
Peak Reflow Temperature (Cel) 260
Terminal Form GULL WING
Terminal Position DUAL
Applications TFT-LCD Panels: VCOM Driver
Min Operating Temperature -40°C
Max Operating Temperature 85°C
Terminal Finish Matte Tin (Sn) - annealed
Type Calibrator
ECCN Code EAR99
Number of Terminations 8
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
JESD-609 Code e3
Packaging Tape & Reel (TR)
Physical
Number of Pins 8
Package / Case 8-TSSOP, 8-MSOP (0.118, 3.00mm Width)
Mounting Type Surface Mount
Mount Surface Mount
Supply Chain
Lifecycle Status NRND (Last Updated: 7 months ago)
Factory Lead Time 20 Weeks
