GS9064-CKDE3

Semtech Corporation
RoHS
RoHS RoHS compliant
Package 16-SOIC (0.154, 3.90mm Width)
Category Integrated Circuits (ICs) / Linear - Video Processing
Description Cable Equalizer Tube GS9064 Surface Mount video processing unit 9.91mm 3.3V 70C
PDF
/
Buying Options
Total Price: USD $66.36
Unit Price: USD $66.35845
≥1 USD $66.35845
≥10 USD $54.4483
≥100 USD $52.74685
≥500 USD $51.0454
≥1000 USD $49.34395
Inventory: 997
Minimum: 1
-
+

Technical Details

Physical

Mount Surface Mount
Mounting Type Surface Mount
Package / Case 16-SOIC (0.154, 3.90mm Width)

Technical

Packaging Tube
Published 1999
Series HD-LINX? II
Part Status Obsolete
Moisture Sensitivity Level (MSL) 3 (168 Hours)
Number of Terminations 16
Type Cable Equalizer
Max Operating Temperature 70°C
Min Operating Temperature 0°C
Applications Video
HTS Code 8542.39.00.01
Subcategory Other Telecom ICs
Technology BIPOLAR
Terminal Position DUAL
Terminal Form GULL WING
Peak Reflow Temperature (Cel) 260
Number of Functions 1
Supply Voltage 3.3V
Terminal Pitch 1.27mm
Time@Peak Reflow Temperature-Max (s) 40
Base Part Number GS9064
JESD-30 Code R-PDSO-G16
Power Supplies 3.3V
Temperature Grade COMMERCIAL

Dimensions

Height Seated (Max) 1.75mm
Length 9.91mm
Width 3.9mm

Compliance

Radiation Hardening No
RoHS Status RoHS Compliant
Lead Free Lead Free
