ISL24202IRTZ
RoHS
RoHS compliant
RoHS compliantPackage 8-WDFN Exposed Pad
Category Integrated Circuits (ICs) / Linear - Video Processing
Description
Calibrator Tube ISL24202 Surface Mount video processing unit 3mm 19V -40C
PDF
/
Buying Options
Total Price: USD $1.33
Unit Price: USD $1.327342
≥1 USD $1.327342
≥200 USD $0.513344
≥500 USD $0.496276
≥1000 USD $0.487086
Inventory: 1175
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Dimensions
Width 3mm
Length 3mm
Height Seated (Max) 0.8mm
Technical
Supply Voltage-Min (Vsup) 4.5V
Temperature Grade INDUSTRIAL
Supply Voltage-Max (Vsup) 19V
Operating Temperature (Min) -40°C
Operating Temperature (Max) 85°C
Qualification Status Not Qualified
JESD-30 Code S-PDSO-N8
Pin Count 8
Base Part Number ISL24202
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Terminal Pitch 0.65mm
Supply Voltage 18V
Number of Functions 1
Peak Reflow Temperature (Cel) 260
Terminal Form NO LEAD
Terminal Position DUAL
HTS Code 8542.39.00.01
Applications LCD Drive, Reference Voltage Generator
Terminal Finish Matte Tin (Sn) - annealed
Type Calibrator
Number of Terminations 8
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
JESD-609 Code e3
Packaging Tube
Physical
Surface Mount YES
Package / Case 8-WDFN Exposed Pad
Mounting Type Surface Mount
Supply Chain
Factory Lead Time 14 Weeks
Alternative Model
