TDA9983BHW/15/C1:5
RoHS
RoHS compliant
RoHS compliantPackage 80-TQFP Exposed Pad
Category Integrated Circuits (ICs) / Linear - Video Processing
Description
ROHS3Compliant GULL WING COMMERCIAL QUAD Video (Function) 70C 3.6V 200mA 12mm
PDF
/
Inventory: 6682
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Dimensions
Width 12mm
Length 12mm
Height Seated (Max) 1.2mm
Technical
Supply Current-Max 200mA
Supply Voltage-Min (Vsup) 3V
Temperature Grade COMMERCIAL
Power Supplies 1.83.3V
Supply Voltage-Max (Vsup) 3.6V
Operating Temperature (Max) 70°C
Qualification Status Not Qualified
JESD-30 Code S-PQFP-G80
Pin Count 80
Base Part Number TDA9983
Terminal Pitch 0.5mm
Number of Functions 1
Terminal Form GULL WING
Terminal Position QUAD
Subcategory Other Consumer ICs
HTS Code 8542.39.00.01
Applications Recorders, Set-Top Boxes
Type Transmitter
Number of Terminations 80
Moisture Sensitivity Level (MSL) 3 (168 Hours)
Part Status Obsolete
Published 2008
Packaging Tray
Physical
Surface Mount YES
Package / Case 80-TQFP Exposed Pad
Mounting Type Surface Mount
