TDA9981BHL/15/C1,5
RoHS
RoHS compliant
RoHS compliantPackage 80-LQFP
Category Integrated Circuits (ICs) / Linear - Video Processing
Description
ROHS3Compliant GULL WING OTHER QUAD Video (Function) 85C 1.95V 200mA 12mm
PDF
/
Buying Options
Total Price: USD $2.95
Unit Price: USD $2.95355
≥1 USD $2.95355
≥10 USD $2.42345
≥100 USD $2.34745
≥500 USD $2.2724
≥1000 USD $2.1964
Inventory: 1282
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Dimensions
Width 12mm
Length 12mm
Height Seated (Max) 1.6mm
Technical
Supply Current-Max 200mA
Supply Voltage-Min (Vsup) 1.65V
Temperature Grade OTHER
Power Supplies 1.83.3V
Supply Voltage-Max (Vsup) 1.95V
Operating Temperature (Max) 85°C
Qualification Status Not Qualified
JESD-30 Code S-PQFP-G80
Pin Count 80
Base Part Number TDA9981
Time@Peak Reflow Temperature-Max (s) 30
Terminal Pitch 0.5mm
Number of Functions 1
Peak Reflow Temperature (Cel) 260
Terminal Form GULL WING
Terminal Position QUAD
Subcategory Other Consumer ICs
Applications Recorders, Set-Top Boxes
Terminal Finish TIN
Type Transmitter
Number of Terminations 80
Moisture Sensitivity Level (MSL) 3 (168 Hours)
Part Status Obsolete
Pbfree Code yes
JESD-609 Code e3
Published 2008
Packaging Tape & Reel (TR)
Physical
Surface Mount YES
Package / Case 80-LQFP
Mounting Type Surface Mount
