LT1675CGN#TRPBF
RoHS
RoHS compliant
RoHS compliantPackage 16-SSOP (0.154, 3.90mm Width)
Category Integrated Circuits (ICs) / Linear - Video Processing
Description
Multiplexer Tape & Reel (TR) LT1675 Surface Mount video processing unit 4.89mm 42mA 6V 70C
PDF
/
Buying Options
Total Price: USD $6.68
Unit Price: USD $6.6785
≥1 USD $6.6785
≥10 USD $5.4796
≥100 USD $5.3086
≥500 USD $5.1376
≥1000 USD $4.9666
Inventory: 1388
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Dimensions
Width 3.5mm
Length 4.89mm
Height Seated (Max) 1.75mm
Technical
Neg Supply Voltage-Min (Vsup) -4V
Switching BREAK-BEFORE-MAKE
Neg Supply Voltage-Max (Vsup) -6V
Neg Supply Voltage-Nom (Vsup) -5V
Supply Current-Max (Isup) 42mA
Number of Channels 2
Supply Voltage-Min (Vsup) 4V
Temperature Grade COMMERCIAL
Power Supplies +-5V
Supply Voltage-Max (Vsup) 6V
Operating Temperature (Max) 70°C
Qualification Status Not Qualified
JESD-30 Code R-PDSO-G16
Pin Count 16
Base Part Number LT1675
Time@Peak Reflow Temperature-Max (s) 30
Terminal Pitch 0.635mm
Supply Voltage 5V
Number of Functions 1
Peak Reflow Temperature (Cel) 260
Terminal Form GULL WING
Terminal Position DUAL
Technology BIPOLAR
HTS Code 8542.39.00.01
Applications Drivers, Processing, Switching
Terminal Finish Matte Tin (Sn)
Type Multiplexer
ECCN Code EAR99
Number of Terminations 16
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
JESD-609 Code e3
Published 2005
Packaging Tape & Reel (TR)
Physical
Surface Mount YES
Package / Case 16-SSOP (0.154, 3.90mm Width)
Mounting Type Surface Mount
Supply Chain
Factory Lead Time 8 Weeks
