ADV7612WBSWZ
RoHS
/
Package LQFP
Category Integrated Circuits (ICs) / Linear - Video Processing
Description
Contains Lead RoHS Compliant GULL WING I2C video processing unit 85C 1.5B 1.89V 14mm
PDF
/
Buying Options
Total Price: USD $159.71
Unit Price: USD $159.7102
≥1 USD $159.7102
≥10 USD $143.18875
Inventory: 703
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Contains Lead
RoHS Status RoHS Compliant
Dimensions
Width 14mm
Length 14mm
Height Seated (Max) 1.6mm
Technical
Supply Voltage1-Max 3.46V
Supply Voltage1-Min 3.14V
Supply Voltage1-Nom 3.3V
Receive Delay-Max 300 ns
Interface Standard I2C
Receiver Number of Bits 1
Input Characteristics STANDARD
Sampling Rate 225 Msps
Resolution 1.5 B
Differential Output NO
Logic Function Receiver
Supply Voltage-Min (Vsup) 1.71V
Temperature Grade INDUSTRIAL
Supply Voltage-Max (Vsup) 1.89V
Qualification Status Not Qualified
Pin Count 100
Time@Peak Reflow Temperature-Max (s) 30
Terminal Pitch 0.5mm
Supply Voltage 1.8V
Number of Functions 1
Peak Reflow Temperature (Cel) 260
Terminal Form GULL WING
Terminal Position QUAD
Technology CMOS
HTS Code 8542.39.00.01
Min Operating Temperature -40°C
Max Operating Temperature 85°C
Terminal Finish Matte Tin (Sn)
ECCN Code EAR99
Number of Terminations 100
Moisture Sensitivity Level (MSL) 3
Pbfree Code no
JESD-609 Code e3
Physical
Number of Pins 100
Surface Mount YES
Package / Case LQFP
Supply Chain
Lifecycle Status PRODUCTION (Last Updated: 4 weeks ago)
