TLV3501AZQDBVRQ1
RoHS
RoHS compliant
RoHS compliantPackage SOT-23-6
Category Integrated Circuits (ICs) / Linear - Comparators
Description
Tape & Reel (TR) TLV3501 CMOS Push-Pull Rail-to-Rail TTL Automotive AEC-Q100 comparator circuit 10pA 10ns 2.9mm 6mV
PDF
/
Buying Options
Total Price: USD $3.48
Unit Price: USD $3.4848
≥1 USD $3.4848
≥10 USD $3.12664
≥100 USD $2.955744
≥500 USD $2.561592
≥1000 USD $2.430243
≥3000 USD $2.180658
Inventory: 1237
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Lead Free
RoHS Status ROHS3 Compliant
Dimensions
Thickness 1.2mm
Width 1.6mm
Length 2.9mm
Height 1.45mm
Technical
CMRR, PSRR (Typ) 70dB CMRR, 100dB PSRR
Hysteresis 6mV
Current - Input Bias (Max) 10pA @ 5.5V
Voltage - Input Offset (Max) 6.5mV @ 5.5V
Current - Quiescent (Max) 5mA
Input Bias Current 10pA
Max Input Current 10pA
Supply Voltage Limit-Max 5.5V
Power Supply Rejection Ratio (PSRR) 100dB
Input Offset Voltage (Vos) 6.5mV
Voltage - Supply, Single/Dual (±) 2.7V~5.5V ±1.35V~2.75V
Common Mode Rejection Ratio 100 dB
Quiescent Current 5mA
Propagation Delay 10 ns
Number of Elements 1
Output Type CMOS, Push-Pull, Rail-to-Rail, TTL
Base Part Number TLV3501
Terminal Pitch 0.95mm
Supply Voltage 2.7V
Number of Functions 1
Terminal Form GULL WING
Terminal Position DUAL
Subcategory Comparator
Terminal Finish Matte Tin (Sn)
Type General Purpose
ECCN Code EAR99
Number of Terminations 6
Moisture Sensitivity Level (MSL) 3 (168 Hours)
Part Status Active
Pbfree Code yes
JESD-609 Code e3
Series Automotive, AEC-Q100
Packaging Tape & Reel (TR)
Operating Temperature -40°C~125°C
Physical
Number of Pins 6
Package / Case SOT-23-6
Mounting Type Surface Mount
Mount Surface Mount
Supply Chain
Lifecycle Status ACTIVE (Last Updated: 4 days ago)
Factory Lead Time 6 Weeks
