TLV3404CDRG4
RoHS
/
Package SOIC
Category Integrated Circuits (ICs) / Linear - Comparators
Description
Tape & Reel (TR) 0.0015muA Nickel/Palladium/Gold (Ni/Pd/Au) e4 comparator circuit 0.00025muA 30mus 8.65mm 3.6mV
PDF
/
Buying Options
Total Price: USD $4.82
Unit Price: USD $4.823465
≥1 USD $4.823465
≥10 USD $4.550436
≥100 USD $4.292865
≥500 USD $4.049866
≥1000 USD $3.820632
Inventory: 1711
Minimum: 1
-
+
Technical Details
Physical
Mount Surface Mount
Package / Case SOIC
Number of Pins 14
Weight 122.413241mg
Technical
Packaging Tape & Reel (TR)
JESD-609 Code e4
Moisture Sensitivity Level (MSL) 1
Number of Terminations 14
ECCN Code EAR99
Type General Purpose
Terminal Finish Nickel/Palladium/Gold (Ni/Pd/Au)
Max Operating Temperature 125°C
Min Operating Temperature -40°C
Subcategory Comparator
Terminal Position DUAL
Terminal Form GULL WING
Peak Reflow Temperature (Cel) 260
Number of Functions 4
Supply Voltage 2.7V
Terminal Pitch 1.27mm
Pin Count 14
Temperature Grade COMMERCIAL
Number of Channels 4
Max Supply Voltage 16V
Min Supply Voltage 2.5V
Power Dissipation-Max 1.022W
Nominal Supply Current 640nA
Power Dissipation 1.022W
Max Supply Current 640nA
Current - Output 10mA
Propagation Delay 300 μs
Quiescent Current 950nA
Response Time 30 μs
Common Mode Rejection Ratio 88 dB
Current - Input Bias 250pA
Input Offset Voltage (Vos) 3.6mV
Voltage Gain 120dB
Average Bias Current-Max (IIB) 0.0015μA
Power Supply Rejection Ratio (PSRR) 105dB
Max Dual Supply Voltage 8V
Min Dual Supply Voltage 1.25V
Bias Current-Max (IIB) @25C 0.00025μA
Dimensions
Height Seated (Max) 1.75mm
Length 8.65mm
Width 3.9mm
Compliance
Radiation Hardening No
RoHS Status RoHS Compliant
Lead Free Lead Free
