TLC374CDG4
RoHS
RoHS compliant
RoHS compliantPackage 14-SOIC (0.154, 3.90mm Width)
Category Integrated Circuits (ICs) / Linear - Comparators
Description
Tube TLC374 CMOS MOS Open-Drain TTL LinCMOS? comparator circuit 5pA @ 5V 200ns 8.65mm 5V
PDF
/
Buying Options
Total Price: USD $0.94
Unit Price: USD $0.9386
≥1 USD $0.9386
≥10 USD $0.77045
≥100 USD $0.7467
≥500 USD $0.722
≥1000 USD $0.69825
Inventory: 6006
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Lead Free
RoHS Status ROHS3 Compliant
REACH SVHC No SVHC
Radiation Hardening No
Dimensions
Thickness 1.58mm
Width 3.91mm
Length 8.65mm
Height 1.75mm
Technical
Ambient Temperature Range High 70°C
Current - Input Bias (Max) 5pA @ 5V
Voltage - Input Offset (Max) 5mV @ 5V
Input Bias Current 600pA
Dual Supply Voltage 5V
Supply Voltage Limit-Max 18V
Average Bias Current-Max (IIB) 0.00003μA
Input Offset Voltage (Vos) 6.5mV
Output Current per Channel 6mA
Voltage - Supply, Single/Dual (±) 3V~16V ±1.5V~8V
Response Time 200 ns
Quiescent Current 800μA
Max Supply Current 600μA
Output Current 20mA
Power Dissipation 500mW
Nominal Supply Current 300μA
Power Supplies 5V
Number of Elements 4
Operating Supply Voltage 15V
Output Type CMOS, MOS, Open-Drain, TTL
Pin Count 14
Base Part Number TLC374
Terminal Pitch 1.27mm
Supply Voltage 5V
Number of Functions 4
Peak Reflow Temperature (Cel) 260
Terminal Form GULL WING
Terminal Position DUAL
Max Power Dissipation 500mW
Subcategory Comparator
Terminal Finish Nickel/Palladium/Gold (Ni/Pd/Au)
Type Differential
ECCN Code EAR99
Number of Terminations 14
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Pbfree Code yes
JESD-609 Code e4
Series LinCMOS?
Packaging Tube
Operating Temperature 0°C~70°C
Physical
Weight 122.413241mg
Number of Pins 14
Package / Case 14-SOIC (0.154, 3.90mm Width)
Mounting Type Surface Mount
Mount Surface Mount
Supply Chain
Lifecycle Status ACTIVE (Last Updated: 2 days ago)
Factory Lead Time 6 Weeks
