TLC3702CPSRG4
RoHS
RoHS compliant
RoHS compliantPackage 8-SOIC (0.209, 5.30mm Width)
Category Integrated Circuits (ICs) / Linear - Comparators
Description
Tape & Reel (TR) TLC3702 CMOS Push-Pull TTL LinCMOS? comparator circuit 5pA 2700ns 6.2mm 5mV
PDF
/
Buying Options
Total Price: USD $0.67
Unit Price: USD $0.67165
≥1 USD $0.67165
≥10 USD $0.551
≥100 USD $0.5339
≥500 USD $0.5168
≥1000 USD $0.4997
Inventory: 1348
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 6 Weeks
Lifecycle Status ACTIVE (Last Updated: 1 week ago)
Physical
Mount Surface Mount
Mounting Type Surface Mount
Package / Case 8-SOIC (0.209, 5.30mm Width)
Number of Pins 8
Weight 122.611688mg
Technical
Operating Temperature 0°C~70°C
Packaging Tape & Reel (TR)
Series LinCMOS?
JESD-609 Code e4
Pbfree Code yes
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 8
ECCN Code EAR99
Type General Purpose
Terminal Finish Nickel/Palladium/Gold (Ni/Pd/Au)
Subcategory Comparator
Packing Method TR
Max Power Dissipation 1W
Terminal Position DUAL
Terminal Form GULL WING
Peak Reflow Temperature (Cel) 260
Number of Functions 2
Supply Voltage 5V
Base Part Number TLC3702
Pin Count 8
Output Type CMOS, Push-Pull, TTL
Operating Supply Voltage 5V
Number of Elements 2
Power Supplies 5V
Nominal Supply Current 40μA
Power Dissipation 1W
Output Current 20mA
Max Supply Current 40μA
Propagation Delay 4.5 μs
Quiescent Current 50μA
Response Time 2700 ns
Common Mode Rejection Ratio 84 dB
Voltage - Supply, Single/Dual (±) 3V~16V
Output Current per Channel 8mA
Input Offset Voltage (Vos) 5mV
Average Bias Current-Max (IIB) 0.00003μA
Power Supply Rejection Ratio (PSRR) 84dB
Max Input Current 5pA
Input Bias Current 600pA
Current - Quiescent (Max) 50μA
Voltage - Input Offset (Max) 5mV @ 10V
Current - Input Bias (Max) 5pA @ 5V
CMRR, PSRR (Typ) 84dB CMRR
Dimensions
Height 2mm
Length 6.2mm
Width 5.3mm
Thickness 1.95mm
Compliance
Radiation Hardening No
RoHS Status ROHS3 Compliant
Lead Free Lead Free
